Tsudakoma RNCM-301R 12 Rotary Table / 4th Axis
The Tsudakoma RNCM-301R 12 Rotary Table / 4th Axis is a high-quality CNC-controlled workholding unit manufactured by Tsudakoma in Japan. This rotary table allows for horizontal and vertical setting positions, making it versatile for various manufacturing needs. With a 12 diameter and a sturdy construction, this unit is designed to provide precise and reliable performance for metalworking and manufacturing applications.
Horizontal Vertical Red Beam Rotary Laser Level with Receiver and Remote
Horizontal Vertical Red Beam Rotary Laser Level with Receiver and Remote. Comes with receiver, remote, glasses, and carry case.
High-precision HV3/4/5/6/8/10/12/14/16-inch Vertical and Horizontal Indexing
High-precision HV3/4/5/6/8/10/12/14/16-inch vertical and horizontal indexing dial milling machine rotary table. Specifications HV-4 inch HV-6 inch HV-8 inch HV-10 inch HV-12 inch HV-14 inch HV-16 inch. Diameter 110mm 150mm 200mm 250mm 300mm 350mm 400mm. Taper hole Table center MT2 MT2 MT3 MT3 MT4 MT4 MT4 MT4. Table vertical 81.5mm 100mm 135mm 165mm 195mm 230mm 260mm. Table T-slot width 14. Positioning pin width 12 16 18. Number of slots in table top Three slots Four slots Six slots. Turbine ratio 1:75 1:90. Maximum load capacity Horizontal 70KG 100KG 150KG 200KG 250KG 300KG 350KG. Maximum Load Vertical 30kg 50kg 75kg 100kg 125kg 150kg 175kg. Indexing error 0.1° 0.05° 0.02. Weight 9kg 14kg 28kg 50kg 75kg 88kg 105kg. Item Diameter 110mm 150mm 200mm 250mm 300mm 350mm 400mm Taper hole Table center MT2 MT2 MT3 MT3 MT4 MT4 MT4 MT4 Table vertical 81.5mm 100mm 135mm 165mm 195mm 230mm 260mm Center Height Table T-slot width 14 Positioning pin width 12 16 18 Number of slots in table top Three slots Four slots Six slots Turbine ratio 1:75 1:90 Maximum load capacity Horizontal 70KG 100KG 150KG 200KG 250KG 300KG 350KG Maximum Load Vertical 30kg 50kg 75kg 100kg 125kg 150kg 175kg Indexing error 0.1° 0.05° 0.02 Weight 9kg 14kg 28kg 50kg 75kg 88kg 105kg.
High Precision CNC Rotary Table with Stepper Motor
High Precision CNC Rotary Table with Stepper Motor.
Buyohlic Horizontal Vertical HV8 8 (200 mm) -3 slots Rotary Milling Indexing
A rotary table is a precision tool used predominantly in metalworking, particularly in machining operations like milling and drilling. Its primary function lies in enabling machining at precise angular intervals around a fixed point, commonly referred to as indexing. This capability facilitates the creation of intricate geometries, circular features, and multi-sided machining without the need for manual repositioning of the workpiece. By mounting the workpiece on the rotary table and rotating it, machinists can execute complex operations such as gear cutting, spiral grooving, and helical cuts with high precision. Additionally, rotary tables are essential for tasks requiring circular or arc-shaped machining, offering versatility and efficiency in manufacturing processes. Upgrade your machining capabilities with our HV8 Rotary Table, designed for high precision and durability. Ideal for both professional and hobbyist applications, this rotary table is built to handle diverse machining tasks with ease and accuracy. Disc Diameter : 200 mm – Optimized for a wide range of setups and part sizes. Turbine Worm Speed Ratio : 1:90 – Ensures smooth, controlled rotation, perfect for precision work. Vertical Center Height : 135 mm – Accommodates varied machining needs, making it a versatile addition to your setup. Weight : 30 kg – Stable and robust, it minimizes vibrations, enhancing accuracy. Constructed with premium materials, this HV8 rotary table withstands heavy-duty use while maintaining consistent, reliable performance. Its 3-slot design allows for secure, versatile clamping of workpieces, ensuring ease of use across various machining applications. The 1:90 gear ratio provides precise control over positioning, making it well-suited for detailed work that requires accuracy. The compact yet sturdy design fits seamlessly into your workspace, allowing for flexibility whether working on vertical or horizontal setups. Perfect for milling, drilling, and even more complex operations like engraving or machining circular parts.
Lot of 5 Precision Machining Rotary Tables & Chucks & 4 Face Plates 320mm ts320A
Lot of 5 Precision Machining Rotary Tables & Chucks & 3 Face Plates, Everything came from a local machine shop and im not a machinist so this stuff is foreign to me, see images for more info. Most have no brand names that I can find but a more detailed description of each is below. Rotary table (green base) with chuck, is stamped made in japan (3 jaw 8/210mm chuck). Largest one is a 320mm. Rotary table with face plate, name plate is in. Has a micrometer turning handle that spins the table. 4 Jaw 10 chuck (No markings) has screws coming out bottom. Amestra 11 3/4 3 jaw chuck, plain back. 4 Round face plates, No markings on any them (2) 16″ (2) 15″, 1 has a lot rust, 1 have some, others look ok.
HV 4 (100 mm) Tilting Milling Indexing Horizontal Vertical Rotary Table with
Use of product – A rotary table is a precision work positioning device used in metalworking. It enables the operator to drill or cut work at exact intervals around a fixed (usually horizontal or vertical) axis. A round vise is used for securely holding round or cylindrical workpieces during machining, drilling, grinding, or inspection processes. Its design allows for stable and precise positioning, facilitating accurate and consistent operations on the workpiece. 4 (100 mm) Rotary Table. 360-Degree Graduation: The table is graduated a full 360 degrees, allowing for precise control and positioning of the workpiece. The clear markings ensure easy and accurate angle setting for all your milling tasks. Worm Gear Ratio: 1:36 The gear ratio means that one full rotation of the handle turns the table by 10 degrees, providing fine control over the movement and ensuring precision in every operation. Vertical Position Center Height: 2-1/16 (50 mm approx) The center height in the vertical position is 2-1/16 inches, which aligns perfectly with the smaller milling machine setups, offering versatility in workpiece positioning. Handwheel Graduations: The handwheel is graduated in divisions of 10 minutes, allowing for highly detailed adjustments. The scale can also be set to zero, making it easy to track and repeat your adjustments for consistent results. Mounting Flexibility: The Regular model can be mounted in both horizontal and vertical positions, enhancing its versatility for a wide range of applications. Whether you need flat or angled cuts, this rotary table can handle it with ease. Made form Quality close grain Caste Iron -Designed to fit our 3″ (75 mm) & 4″(100 mm) Rotary Tables. Diameter of Base : 80 mm Jaw Width : 54 mm Jaw Depth: 20 mm Jaw Opening : 32 mm Height : 29 mm. These vices are counter- drilled in a manner that these can fit to a 3 as well 4 slot table. The moving jaw has V-grooves to hold Round objects. Precisely Ground on Base, Top, Jaws & Base. Rest Body is painted for a long rust free life. 100 mm Diameter Caste Iron Round Vise vice -Made from Close grain Caste Iron. Designed to fit our 4 (100 mm) Regular & tilting models of Rotary Table. Vice is counter drilled in a manner that it can fit to both 3 as well as 4 Slots Rotary Table. Diameter of Base : 105 mm Jaw Width : 75 mm Jaw Depth: 21 mm Jaw Opening : 40 mm Height : 32 mm.
Rotary Table for Milling Machines, 4”/ 100 mm, Horizontal Vertical Model
4-Inch Rotary Table for Milling Machine. Our 4”/100 mm diameter rotary table is the perfect companion for small milling machines or specialized machinery and is designed for intricate and complex dividing cuts. Embrace the efficiency and versatility of our 4-inch rotary table and take your milling projects to the next level of accuracy. Our rotary table comes with a 3-jaw chuck and requires additional installation! We offer two types of jaws, internal jaw and external jaw, which easily open and close with a T-shaped chuck wrench, ensuring a secure and precise grip on your workpieces. Enjoy the precise machining with our meticulously designed milling rotary table featuring a worm gear ratio of 1:36 and a fine, clear scale. Every rotation is under your control, with a dedicated degree lock. Once you set your angle, it stays put, ensuring stability and consistency in your work. Discover unparalleled versatility with our milling machine rotary table, ingeniously designed for both horizontal and vertical applications. The precise positioning slot on the bottom ensures the rotary table remains stable and shake-free during operation. Our rotary table is crafted from HT250 cast iron for exceptional wear resistance and high hardness and is a staple in precision and heavy-duty machining industries. Choose our rotary table for a lasting addition to your workshop, where strength meets precision at every turn.
