5 (125mm) HV5 II Horizontal Vertical Rotary Table for Milling Machine
Horizontal & Vertical HV5 II 5 Inch (125mm) Rotary Milling Indexing Table. PRECISION HV5 ROTARY MILLING TABLE: Heavy-duty HV5 II horizontal and vertical rotary table featuring a 125 mm (5-inch) graduated table, precision worm gear mechanism and 360° rotation. Designed for accurate work positioning, circular machining, drilling, milling and indexing operations. COMPLETE DIVIDING PLATE SET: Supplied with three circular dividing plates and indexing accessories, including a crank handle, sector mechanism, mounting bracket, fixing screws and associated components. Enables controlled indexing for machining equally spaced holes, slots, grooves and other repetitive features around a workpiece. HORIZONTAL & VERTICAL OPERATION: Versatile two-position design allows the rotary table to be mounted horizontally or vertically on a milling machine. Suitable for machining circular components, angular features, radial patterns, gear-related work and precision positioning applications. PRECISION WORM GEAR DRIVE: Features a 1:72 worm gear reduction ratio, providing controlled rotary movement. One complete revolution of the handwheel rotates the table by 5°. The table has 360° graduations, while the handwheel is graduated for finer angular adjustment. COMPACT, RIGID & MACHINE-READY DESIGN: Features a 155 × 131 mm base, 12 mm T-slots, 2MT centre bore and 10 kg overall weight. Ideal for toolrooms, engineering workshops, maintenance facilities, machinists and precision metalworking applications. Buyohlic HV5 II 5-Inch Horizontal & Vertical Rotary Milling Table with Dividing Plate Set. Upgrade your milling capabilities with the Buyohlic HV5 II 125 mm Horizontal & Vertical Rotary Milling Table, supplied with a comprehensive three-piece dividing plate set and indexing accessories. Designed for precision metalworking, this combination provides accurate workpiece positioning, controlled angular movement and mechanical indexing capabilities for a wide variety of milling and drilling operations. Precision Rotary Milling Performance. The HV5 II features a 125 mm (5-inch) graduated rotary table driven by a precision worm and worm-wheel mechanism with a 1:72 reduction ratio. One complete revolution of the handwheel rotates the table through 5 degrees, allowing controlled positioning throughout its full 360-degree rotation. The graduated handwheel facilitates finer angular adjustments for precision machining applications. Horizontal and Vertical Mounting. The versatile horizontal and vertical configuration allows the table to be positioned according to the machining requirements. It is suitable for circular milling, angular machining, drilling equally spaced holes, cutting slots, machining curved profiles and positioning workpieces at specific angular intervals. Three-Piece Dividing Plate and Indexing Accessory Set. The included dividing mechanism expands the functionality of the rotary table by enabling mechanical indexing for repetitive and equally spaced machining operations. The accessory set consists of three circular dividing plates with multiple concentric hole patterns, along with the associated crank handle, sector mechanism, mounting bracket, fixing screws and other installation components. When correctly installed and configured, the dividing mechanism helps machinists achieve repeatable angular divisions for applications such as gear-related machining, bolt-circle drilling, fluting, slotting and other precision indexing tasks. Rigid Construction and Practical Machine Compatibility. The compact base measures 155 × 131 mm and incorporates 12 mm T-slots for mounting and securing the assembly to a suitable milling machine table. The 2MT centre bore provides a facility for compatible taper-mounted tooling and accessories. Its 10 kg overall weight makes it a practical solution for smaller milling machines and engineering workshops. Whether used for general workshop machining, toolmaking, prototyping or precision component manufacturing, the Buyohlic HV5 II rotary table with dividing plate set offers a versatile solution for accurate rotary positioning and indexing operations. Table Diameter: 125 mm / 5 inches. Worm Gear Ratio: 1:72. Handwheel Movement: 5° table rotation per complete handwheel revolution. Handwheel: Graduated in seconds. Base Dimensions: 155 × 131 mm. Horizontal Height: 86 mm. Centre Height in Vertical Position: 89 mm. T-Slot Width: 12 mm. Approximate Overall Weight: 10 kg. Configuration: Horizontal and Vertical. Accessories: Three Dividing Plates and Indexing Mechanism Accessories. Precision circular milling and drilling. Equally spaced hole and slot machining. Angular indexing and workpiece positioning. Fluting and radial machining. Toolroom and engineering workshop applications. Prototype and small-batch component manufacturing. Package Configuration: HV5 II Rotary Milling Table with Three-Piece Dividing Plate Set and Associated Indexing Accessories.
4 Inch 100mm Horizontal Vertical Rotary Table with 4 Slots for Milling Machine
The 4-inch (100 mm) Horizontal and Vertical Rotary Table is a versatile machining accessory designed for milling machines and precision metalworking applications. Its dual-position design allows horizontal or vertical mounting, making it suitable for circular milling, drilling, indexing, and angular machining operations. The four-slot table provides clamping options for compatible workpieces and accessories. Ideal for engineering workshops, toolrooms, and machining enthusiasts.
8 Inch Horizontal Vertical Rotary Table for Milling and Drilling, MT-3
8 Inch Horizontal Vertical Rotary Table for Milling and Drilling, MT-3. Dual Orientation: Designed for horizontal and vertical use. Table Diameter: The table is 8 inches in diameter. Material: Made from HT200 casting. Reduction Ratio: Features a 1:90 reduction ratio. Center Bore: Has an MT-3 center bore. Included Components: The source description lists a wrench and screw. This rotary table is designed for horizontal and vertical milling, drilling, and boring applications. It has an 8-inch table, an MT-3 center bore, and a 1:90 reduction ratio. The listed material is HT200 casting; a wrench and screw are also mentioned. Need more than the quantity listed? Tracking is added to your order as soon as it is available. We are happy to help. Questions about this item? Thanks for shopping with WeShipNow.
Horizontal Vertical Rotary Table 3-Slot Rotary Table 360? Rotary Adjustment
Specifications Material: FC30 Cast Iron Color: Black, Silver Mounting Required: Yes Number of T-Slot: 3 Worm Gear Transmission Ratio: 1:90 Worm Gear Module: 1.5mm/0.06inch Max. Load Capacity (Horizontal): 100kg/220 lbs Max. Load Capacity (Vertical): 50kg/110 lbs Indexing Accuracy: 0.05° Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1° Large Wheel Scale Range: 360° Gross Weight: 12.6kg/27.78 lbs Net Weight: 12.06kg/26.59 lbs Handwheel Diameter: 12.1cm/4.7inch Product Size (Vertical): 3110.624.2cm/12.24.19.5inch Package Size: 31.52616cm/12.410.246.3inch Package Included 1 3-slot Rotary Table Other Accessories for Installation. Welcome to rongbest123 again. The 3-slot rotary table is a precision device designed for sophisticated mechanical processing. It’s constructed from FC30 cast iron and integrated with advanced technologies, ensuring longevity even in demanding machining environments. It can be flexibly switched between horizontal and vertical orientations to adapt to a wide range of machining tasks, making it a powerful tool to enhance machining precision and efficiency. Made of FC30 cast iron, it features excellent wear tolerance and structural stability, laying a solid foundation for long-term use. With a worm gear transmission ratio of 1:90 and a worm gear module of 0.06 inches, it ensures smooth and powerful transmission. The indexing accuracy is 0.05°, meeting the high-precision requirements for processing positioning. Moreover, the easy-to-read, clear graduations provide great convenience for use. It has a maximum load capacity of 220 lbs in the horizontal state and 110 lbs in the vertical state. The working condition can be flexibly switched according to processing needs, meeting different load requirements. Equipped with a precision handwheel, where 30 small scales equal 1°, one full rotation of the handwheel corresponds to 4°. The large wheel offers a 360° scale range, enabling precise and accurate angular adjustments during machining use. Equipped with a spindle locking mechanism, compared with the traditional double-sided pressure plate design, it has a stronger locking force. It can remain highly stable during use, effectively improving machining accuracy and safety. They enable secure and flexible installation on various machining equipment, ensuring stable positioning during use. There is a reset screw under the graduated ring of the handwheel. By loosening this screw, the scale can be easily reset to zero, facilitating quick and accurate calibration. It is compatible with milling machines to perform various tasks, such as indexed drilling, milling, circular cutting, boring, and more. Material: FC30 Cast Iron. Number of T-Slot: 3. Worm Gear Transmission Ratio: 1:90. Worm Gear Module: 1.5mm/0.06inch. Load Capacity (Horizontal): 100kg/220 lbs. Load Capacity (Vertical): 50kg/110 lbs. Indexing Accuracy: 0.05°. Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1°. Large Wheel Scale Range: 360°. Gross Weight: 12.6kg/27.78 lbs. Net Weight: 12.06kg/26.59 lbs. Handwheel Diameter: 12.1cm/4.7inch. : 3110.624.2cm/12.24.19.5inch. Package Size: 31.52616cm/12.410.246.3inch. Other Accessories for Installation. Please carefully check if the size is suitable before placing an order. Please use the product within its weight capacity to avoid damage. Please allow for slight color differences caused by the shooting light and a 1-3cm error due to manual measurement, and make sure you do not mind before ordering. Welcome O(? _?)O. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday. High quality, Local warehouse, Brand new. Worm Gear Transmission Ratio. Graduated Ring of the Handwheel Scale. 4° (A Whole Circle)/30 Small Scales Equal 1°. Large Wheel Scale Range. 12.6kg/27.78 lbs. 12.06kg/26.59 lbs. 3110.624.2cm/12.24.19.5inch. 31.52616cm/12.410.246.3inch.
New Horizontal And Vertical Rotary Table With 65 mm 3 Jaw Chuck Backplate USA
SKYLARK TOOLS – 4 / 100mm Rotary Table with 65mm 3-Jaw Chuck. Upgrade your milling setup with this 4 / 100mm Horizontal & Vertical Rotary Table Kit, supplied with a 65mm 3-Jaw Self-Centering Chuck and Precision Backplate. Designed for accurate indexing, drilling, milling, slotting, engraving and gear cutting, the rotary table can be used in both horizontal and vertical positions. ? 4 / 100mm Rotary Table. ? Horizontal & Vertical Operation. ? 65mm 3-Jaw Self-Centering Chuck. ? M14 × 1 Chuck Thread. ? Precision Backplate Included. ? 360° Graduated Table. ? 5° Rim Scale Increments. ?? 4 Precision T-Slots. ? ¼° Handwheel Graduation. ?? Heavy-Duty Cast Iron Construction. ? T-Nuts & Clamping Hardware Included. Reversible Hardened & Ground. 1 × 4 / 100mm Rotary Table. 1 × 65mm 3-Jaw Self-Centering Chuck. 1 × Precision Backplate. T-Nuts & Clamping Hardware. No Tariff or Additional Import Charges for USA Buyers. 4 inch rotary table, 100mm rotary table, horizontal vertical rotary table, 65mm 3 jaw chuck, self centering chuck, milling rotary table, rotary table chuck kit, 100mm rotary table with chuck, milling machine rotary table, indexing rotary table, metalworking rotary table, SKYLARK TOOLS. The price you pay at checkout is the final amount. Any applicable import charges are the.
Dayton 4K751 10 in Manual Rotary Table Horizontal/Vertical Setting Position
Dayton 4K751 10 in Manual Rotary Table Horizontal/Vertical Setting Position. I used a few hours.
360° Hollow Rotary Platform 51, 101 CNC indexing plate Disc Nema23 Motor Kits
CNC Hollow Rotary Table 360 Circular Dividing disc Replace DD motor Cam indexers. 1 Hollow Rotating Table. 1Flange plate (Compatible with both types of motors). 1Nema23 Closed-Loop (1.2/2/3NM)Motor+Drive. High Accuracy Rotating Platform. Repeated positioning accuracy, which is dramatically growing in high-precision industrial automation equipment, glue dispensing machines, the 4th or 5th axis of machine tools, packing machines, photoelectric and visual inspection equipment, indexing plate, laser printer, sorting machine, robot joint, etc. 360-Degree Rotating Table with Hollow Design. It is easy to position and stay at any angle by connecting with a stepper motor or servo motor directly, the actuator comes with a photoelectric sensor (674) bracket to achieve high accuracy position and control, and the hollow design makes it easy to attach the rotating plate and avoid the complex wiring problem. Equipped with Crossed Roller Bearing. Considering the accuracy and stability that may be affected by the lateral force from different directions, the high rigidity crossed roller bearing was adopted, which features high rotational accuracy, stable rotational torque, and high loading capacity, which can ensure the stability and high precision of the rotating platform. This TS Rotary Actuator Fits for Standard. Nema23 Stepper motor, 200W 400W 600W Servo Moto. The rotary table of the hollow rotary platform is of hollow structure, and the motor is connected at the side to facilitate the installation of air. Pipes and wires in the smelting tool. Like the divider and DD motor, it can directly fix the heavy objects on the platform for transmission. Considering the side force and other problems when the product is used, we adopt cross roller bearing, and an anti overturning stable. Ring is set in the middle. In order to better withstand the lateral force load in use. The body is made of aluminum alloy and processed by high-precision CNC to ensure the accuracy of all parts. The gear adopts the. Carburizing heat treatment and grinding process, which can reach the gear accuracy of grade 5 after machining, and its surface hardness. After the assembly of the product is completed, — lapping procedures will be carried out to ensure that the parallelism. And perpendicularity of the end face are within a trace of runout. The accuracy level of some gears of the hollow rotating platform is up to 4, which makes the hollow rotating platform have very small air. We can compensate for the error during assembly by designing the adjustable gear center distance, and the repeated positioning. Accuracy can reach less than 10 arc seconds. The worktable and mechanical arm of the device can be directly installed on the turntable of the hollow rotary platform. Use of mechanism parts such as pulley, it can reduce the working hours and costs of mechanism design, parts deployment, belt state adjustment, etc. The demand for high-precision industrial automation equipment, dispensing machines, fourth or fifth axes of machine tools, packaging machines. Optoelectronic and visual inspection equipment, indexing boards, laser printers, sorting machines, robot joints and other fields is rapidly increasing. 4th Axis Motorized Hollow Rotating Platform Indexing Rotary Can Replace DD MOTOR. 5Axis Electric Hollow Rotating Platform Indexing Rotary Table DD MOTOR Robot Arm. Order placed on the weekends will be handled on next Monday or Tuesday (holiday excluded). We regret that we can not be responsible for any wrong or undeliverable addresses. If you are satisfied with our product, please do the same for us, leave. For us, which means a lot to us, thanks in advance. Do not leave Negative or. Neutral Feedback before Contacting us. We always reply messages. We guarantee against any defective products. We will work on resolving your particular case ASAP.
3-Slot Rotary Table Horizontal Vertical Rotary Table For Milling Machine 100kg
Specifications Material: FC30 Cast Iron Color: Black, Silver Mounting Required: Yes Number of T-Slot: 3 Worm Gear Transmission Ratio: 1:90 Worm Gear Module: 1.5mm/0.06inch Max. Load Capacity (Horizontal): 100kg/220 lbs Max. Load Capacity (Vertical): 50kg/110 lbs Indexing Accuracy: 0.05° Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1° Large Wheel Scale Range: 360° Gross Weight: 12.6kg/27.78 lbs Net Weight: 12.06kg/26.59 lbs Handwheel Diameter: 12.1cm/4.7inch Product Size (Vertical): 3110.624.2cm/12.24.19.5inch Package Size: 31.52616cm/12.410.246.3inch Package Included 1 3-slot Rotary Table Other Accessories for Installation. 3-Slot Rotary Table Horizontal Vertical Rotary Table For Milling Machine 100kg. The 3-slot rotary table is a precision device designed for sophisticated mechanical processing. It’s constructed from FC30 cast iron and integrated with advanced technologies, ensuring longevity even in demanding machining environments. It can be flexibly switched between horizontal and vertical orientations to adapt to a wide range of machining tasks, making it a powerful tool to enhance machining precision and efficiency. Crafted for high-precision mechanical processing, the 3-slot rotary table is a sophisticated precision device. Built from FC30 cast iron and incorporating cutting-edge technologies, it maintains sturdiness even under rigorous machining conditions. Its ability to switch between horizontal and vertical modes allows it to adapt to a wide range of machining tasks, solidifying its role as a powerful tool for enhancing both machining accuracy and efficiency. Sturdy Material: Made of FC30 cast iron, it features excellent wear tolerance and structural stability, laying a solid foundation for long-term use. Robust Build: Crafted from FC30 cast iron, it exhibits superior wear endurance and structural solidity, establishing a reliable foundation for the product’s extended service life. High Working Efficiency: With a worm gear transmission ratio of 1:90 and a worm gear module of 0.06 inches, it ensures smooth and powerful transmission. The indexing accuracy is 0.05°, meeting the high-precision requirements for processing positioning. Moreover, the easy-to-read, clear graduations provide great convenience for use. Efficient Work: Featuring a worm gear ratio of 1:90 and a module of 0.06 inches, it delivers smooth, powerful transmission. With an indexing accuracy of 0.05°, it meets the stringent precision demands of machining positioning. What’s more, the easy-to-read clear graduations bring great convenience for use. Strong Load-bearing Capacity: It has a maximum load capacity of 220 lbs in the horizontal state and 110 lbs in the vertical state. The working condition can be flexibly switched according to processing needs, meeting different load requirements. This flexible load capacity adapts to diverse processing needs, accommodating workpieces of varying weights with ease. Precise Control: Equipped with a precision handwheel, where 30 small scales equal 1°, one full rotation of the handwheel corresponds to 4°. The large wheel offers a 360° scale range, enabling precise and accurate angular adjustments during machining use. Accurate Control: It features a precision handwheel where 30 small scales equal 1°, and one full handwheel rotation corresponds to 4°. The larger wheel provides a 360° scale range, supporting detailed and accurate angular positioning during machining. Stable Cutting: Equipped with a spindle locking mechanism, compared with the traditional double-sided pressure plate design, it has a stronger locking force. It can remain highly stable during use, effectively improving machining accuracy and safety. Enhanced Cutting Stability: Fitted with an innovative spindle locking mechanism, it delivers a stronger clamping force than conventional double-sided pressure plate designs. This ensures exceptional stability during use processes, directly boosting machining precision and safety. Mounting Holes: They enable secure and flexible installation on various machining equipment, ensuring stable positioning during use. Secure Mounting Holes: They enable firm, adaptable installation on a range of machining equipment, ensuring stable positioning during use. Reset Screw: There is a reset screw under the graduated ring of the handwheel. By loosening this screw, the scale can be easily reset to zero, facilitating quick and accurate calibration. Convenient Reset Screw: A reset screw located beneath the handwheel’s graduated ring simplifies calibration. Loosening this screw allows quick, zero-resetting of the scales, facilitating precise adjustments for tasks. It is compatible with milling machines to perform various tasks, such as indexed drilling, milling, circular cutting, boring, and more. Material: FC30 Cast Iron. Number of T-Slot: 3. Worm Gear Transmission Ratio: 1:90. Worm Gear Module: 1.5mm/0.06inch. Load Capacity (Horizontal): 100kg/220 lbs. Load Capacity (Vertical): 50kg/110 lbs. Indexing Accuracy: 0.05°. Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1°. Large Wheel Scale Range: 360°. Gross Weight: 12.6kg/27.78 lbs. Net Weight: 12.06kg/26.59 lbs. Handwheel Diameter: 12.1cm/4.7inch. Product Size (Vertical): 3110.624.2cm/12.24.19.5inch. Package Size: 31.52616cm/12.410.246.3inch. 1 3-slot Rotary Table. Other Accessories for Installation. Please carefully check if the size is suitable before placing an order. Please use the product within its weight capacity to avoid damage. Please allow for slight color differences caused by the shooting light and a 1-3cm error due to manual measurement, and make sure you do not mind before ordering. Feedback is very important to us. It is impossible to address issues if we do not know about them! Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.
3? 80mm Rotary Table for Milling Machines Horizontal & Vertical Precision 4
Low-Profile Precision Design – Compact rotary table ideal for accurate milling operations with limited workspace. ? 3? (80 mm) Table Diameter – Provides stable and precise work positioning for small to medium machining tasks. ? 36:1 Gear Ratio – One full rotation of the handle rotates the table by 10° for controlled and repeatable indexing. ? 5° Graduated Scale – Clearly calibrated table scale allows easy and accurate angular adjustments. ? Horizontal & Vertical Use – Can be mounted in both positions for maximum flexibility in milling operations. ? 4 × 5/16? T-Slots – Ensures secure clamping of workpieces and fixtures. ? Rigid Base Construction – Base dimensions 4-1/8? × 3-1/4? Provide stability and vibration resistance. ?? Workshop Ready – Suitable for milling, drilling, boring, circular cutting, and indexing applications. Item Weight: 8.8 pounds.
Horizontal Vertical Rotary Table, 3-Slot Rotary Table for Milling Machine
Crafted for high-precision mechanical processing, the 3-slot rotary table is a sophisticated precision device. Built from FC30 cast iron and incorporating cutting-edge technologies, it maintains sturdiness even under rigorous machining conditions. Its ability to switch between horizontal and vertical modes allows it to adapt to a wide range of machining tasks, solidifying its role as a powerful tool for enhancing both machining accuracy and efficiency. Robust Build: Crafted from FC30 cast iron, it exhibits superior wear endurance and structural solidity, establishing a reliable foundation for the product’s extended service life. Efficient Work: Featuring a worm gear ratio of 1:90 and a module of 0.06 inches, it delivers smooth, powerful transmission. With an indexing accuracy of 0.05°, it meets the stringent precision demands of machining positioning. What’s more, the easy-to-read clear graduations bring great convenience for use. This flexible load capacity adapts to diverse processing needs, accommodating workpieces of varying weights with ease. Accurate Control: It features a precision handwheel where 30 small scales equal 1°, and one full handwheel rotation corresponds to 4°. The larger wheel provides a 360° scale range, supporting detailed and accurate angular positioning during machining. Enhanced Cutting Stability: Fitted with an innovative spindle locking mechanism, it delivers a stronger clamping force than conventional double-sided pressure plate designs. This ensures exceptional stability during use processes, directly boosting machining precision and safety. Secure Mounting Holes: They enable firm, adaptable installation on a range of machining equipment, ensuring stable positioning during use. Convenient Reset Screw: A reset screw located beneath the handwheel’s graduated ring simplifies calibration. Loosening this screw allows quick, zero-resetting of the scales, facilitating precise adjustments for tasks. It is compatible with milling machines to perform various tasks, such as indexed drilling, milling, circular cutting, boring, and more. Material: FC30 Cast Iron. Number of T-Slot: 3. Worm Gear Transmission Ratio: 1:90. Worm Gear Module: 1.5mm/0.06inch. Load Capacity (Horizontal): 100kg/220 lbs. Load Capacity (Vertical): 50kg/110 lbs. Indexing Accuracy: 0.05°. Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1°. Large Wheel Scale Range: 360°. Gross Weight: 12.6kg/27.78 lbs. Net Weight: 12.06kg/26.59 lbs. Handwheel Diameter: 12.1cm/4.7inch. Product Size (Vertical): 3110.624.2cm/12.24.19.5inch. Package Size: 31.52616cm/12.410.246.3inch. 1 3-slot Rotary Table. Other Accessories for Installation. Please carefully check if the size is suitable before placing an order. Please use the product within its weight capacity to avoid damage. Please allow for slight color differences caused by the shooting light and a 1-3cm error due to manual measurement, and make sure you do not mind before ordering. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday. Horizontal Vertical Rotary Table.
