360° Hollow Rotary Actuator Platform Table rotary indexer Step Servo Indexer CNC

• October 5, 2026
• admin

CNC Hollow Rotary Table 360 Circular Dividing disc Replace DD motor Cam indexers. 1 Hollow Rotating Table. Compatible with both types of motors. High Accuracy Rotating Platform. Repeated positioning accuracy, which is dramatically growing in high-precision industrial automation equipment, glue dispensing machines, the 4th or 5th axis of machine tools, packing machines, photoelectric and visual inspection equipment, indexing plate, laser printer, sorting machine, robot joint, etc. 360-Degree Rotating Table with Hollow Design. It is easy to position and stay at any angle by connecting with a stepper motor or servo motor directly, the actuator comes with a photoelectric sensor (674) bracket to achieve high accuracy position and control, and the hollow design makes it easy to attach the rotating plate and avoid the complex wiring problem. Equipped with Crossed Roller Bearing. Considering the accuracy and stability that may be affected by the lateral force from different directions, the high rigidity crossed roller bearing was adopted, which features high rotational accuracy, stable rotational torque, and high loading capacity, which can ensure the stability and high precision of the rotating platform. This TS Rotary Actuator Fits for Standard. Nema17/23/34 Stepper motor, 200W 400W 600W Servo Moto. The rotary table of the hollow rotary platform is of hollow structure, and the motor is connected at the side to facilitate the installation of air. Pipes and wires in the smelting tool. Like the divider and DD motor, it can directly fix the heavy objects on the platform for transmission. Considering the side force and other problems when the product is used, we adopt cross roller bearing, and an anti overturning stable. Ring is set in the middle. In order to better withstand the lateral force load in use. The body is made of aluminum alloy and processed by high-precision CNC to ensure the accuracy of all parts. The gear adopts the. Carburizing heat treatment and grinding process, which can reach the gear accuracy of grade 5 after machining, and its surface hardness. After the assembly of the product is completed, — lapping procedures will be carried out to ensure that the parallelism. And perpendicularity of the end face are within a trace of runout. The accuracy level of some gears of the hollow rotating platform is up to 4, which makes the hollow rotating platform have very small air. We can compensate for the error during assembly by designing the adjustable gear center distance, and the repeated positioning. Accuracy can reach less than 10 arc seconds. The worktable and mechanical arm of the device can be directly installed on the turntable of the hollow rotary platform. Use of mechanism parts such as pulley, it can reduce the working hours and costs of mechanism design, parts deployment, belt state adjustment, etc. The demand for high-precision industrial automation equipment, dispensing machines, fourth or fifth axes of machine tools, packaging machines. Optoelectronic and visual inspection equipment, indexing boards, laser printers, sorting machines, robot joints and other fields is rapidly increasing. 4th Axis Motorized Hollow Rotating Platform Indexing Rotary Can Replace DD MOTOR. 5Axis Electric Hollow Rotating Platform Indexing Rotary Table DD MOTOR Robot Arm. Please scroll down to view the specific specifications by size! 60mm width(For Nema17 and Nema23 Stepper Motor). Guide to Compatible Motor Sizes. 85mm width(For Nema23 Stepper Moto and 60mm Servo Motor). 130mm width(For Nema23 Stepper and Nema34 Stepper Motor). Order placed on the weekends will be handled on next Monday or Tuesday (holiday excluded). We regret that we can not be responsible for any wrong or undeliverable addresses. If you are satisfied with our product, please do the same for us, leave. For us, which means a lot to us, thanks in advance. Do not leave Negative or. Neutral Feedback before Contacting us. We always reply messages. We guarantee against any defective products. We will work on resolving your particular case ASAP.
